KS692 Top hammer tunnel boring machine specifically designed for rock drilling holes such as anchor bolt holes, blasting holes, and detection holes with a diameter of 45 to 76mm
1. The KS692 powerheads for stable and reliable performance, and maintains efficientrock drilling operations in a wide range of geological and rock formation conditions.
2. Shaogang national standard steel, the material is sufficient, thick, the whole vehicle is stable, with a sense of power, to adapt to a variety of complex and large working conditions。
3. Internationally renowned hydraulic system, Italy Kespa, the United states Eaton, HydraForce, etc; to ensure the reliability of the hydraulic system pressure, flow, internal consumption, the use of more durable, efficient, more accurate and smooth operation.
4. Ergonomics of the design of the set of walking devices to reduce the long distance walking to reduce the operator's work intensity; increase the line of sight, reduce safety hazards.
5. Universal chassis for excavators, supporting wheels, driving teeth, chain rails, large flow rate and large tonnage travel motors, stable and efficient construction even in harsh working conditions.
| Parameter Category | Specification |
| Drilling Diameter | 45–76 mm |
| Compatible Drill Rod Type | T38 / T45 |
| Max. Drill Rod Length | 5,200 mm |
| Single Pass Drilling Depth | 4,500 mm |
| Rock Drill Power | 18 kW |
| Rotation Speed | 250 rpm |
| Rotation Torque | 830 N·m |
| Engine Brand | Guangxi Yuchai |
| Emission Standard | China Stage III |
| Engine Power | 92 kW |
| Electric Motor Rated Power | 75 kW |
| Electric Motor Voltage | 380 V |
| Machine Weight | 9 t |
| Transport Dimensions | 11.2 m (L) × 2.2 m (W) × 2.8 m (H) |
